How To Check Earthing System is Proper or Not?

In the world of electrical safety, earthing (or grounding) is a crucial component that cannot be overlooked. A properly functioning earthing system ensures the safe dissipation of fault currents into the ground, preventing electric shocks, equipment damage, or even fire hazards. But how to check earthing system whether it’s effective or not? This article will dive deep into the essential steps, tools, and standards involved in evaluating the performance of an earthing system.

What is an Earthing System?

Before diving into how to check earthing system, let’s first understand what an earthing system is. An earthing system refers to the electrical connection between certain parts of an electrical installation and the ground (earth). This connection provides a path for electrical currents to safely return to the earth in case of a fault, such as a short circuit, lightning strike, or insulation failure.

A typical earthing system includes:

• Earth electrodes (e.g., rods, plates)

• Earthing conductors

• Earth pits with access for measurement

• Grounding enhancement materials (GEM) like bentonite or charcoal-salt mixtures

Why is Earthing System Check Important?

Understanding how to check earthing system regularly is not just a best practice, it’s a necessity for:

• Ensuring personnel safety from electric shocks

• Protecting electrical and electronic devices

• Preventing over-voltage and power surges

• Meeting national/international electrical safety standards like IEEE 80, IEC 60364, or SNI 0225

Now let’s get into how to check earthing system step by step.

How to Check Earthing System: Key Indicators to Evaluate

1. Visual Inspection

The first step in how to check earthing system is a thorough visual inspection. This includes:

• Inspecting the physical condition of the earth pit, electrode, and conductor

• Checking for signs of corrosion on copper or galvanized rods

• Ensuring proper tightness and cleanliness of all bolted connections

• Verifying whether the earth pit has a proper inspection chamber with access lids

• Making sure that no construction debris, water stagnation, or chemical contaminants are present around the earth pit

Visual Tip: An exposed earth rod or open chamber is a safety hazard and must be immediately addressed.

2. Measurement of Earth Resistance (Using Earth Resistance Tester)

The most common method in how to check earthing system is measuring the earth resistance value. This is done using an earth resistance tester or earth ground tester, typically a three-terminal device. The method is often referred to as the Fall-of-Potential test.

Steps:

1. Disconnect the earthing system from the main panel.

2. Insert the current and potential spikes into the ground (typically 5–10 meters apart).

3. Connect the tester as per manufacturer guidelines (C1, P1, C2, P2 terminals).

4. Measure the resistance value.

Interpretation:

• <1 ohm: Ideal for sensitive equipment or lightning protection

• 1–5 ohms: Acceptable for residential and commercial buildings

• >5 ohms: May need improvement or maintenance

Understanding how to check earthing system by measuring resistance is vital for ensuring that fault currents can dissipate without causing harm.

3. Earth Continuity Test

Another method in how to check earthing system is the earth continuity test, which verifies the connection from equipment body to the grounding system.

Procedure:

• Use a digital multimeter (DMM) set to resistance mode.

• Place one probe on the metallic body of equipment and the other on the earth terminal.

• A reading near 0 ohm indicates good continuity.

• A high resistance (above 1 ohm) means loose connection or corrosion.

This test is crucial for ensuring that any metallic body that could become energized is properly grounded.

4. Touch and Step Voltage Measurement

Understanding how to check earthing system extends to checking step and touch voltage, especially in substations, towers, and industrial areas.

Definitions:

• Touch Voltage: Voltage between a person touching a grounded object and earth.

• Step Voltage: Voltage between two points on the ground 1 meter apart.

Using specialized equipment like a ground potential rise (GPR) tester, you can simulate fault conditions to measure the voltage gradient.

Standards:

• As per IEEE Std 80, touch and step voltages must be within human safety limits.

5. Soil Resistivity Test (Wenner Method)

Soil resistivity is a key factor in grounding performance. Knowing how to check earthing system includes testing the ground’s ability to dissipate current.

Procedure:

• Place four test spikes in a straight line, equally spaced (usually 5m).

• Measure using a soil resistivity meter or earth tester.

• Use the Wenner formula:

  ρ = 2πaR
  where:
  ρ = soil resistivity (ohm-m)
  a = spacing between electrodes (m)
  R = measured resistance (ohms)

Note: Lower soil resistivity is better. If the result is high (>100 ohm-m), use Ground Enhancement Materials (GEM) to improve performance.

6. Clamp-On Earth Tester (Without Disconnection)

For systems that cannot be interrupted, clamp-on earth testers are a valuable tool in how to check earthing system safely and non-invasively.

Usage:

• Clamp the device around the grounding conductor.

• The tester induces a voltage and measures resulting current to calculate resistance.

• Ideal for busy sites or working systems.

Pros:

• No need to shut down equipment

• Quick and easy

• Safe and contactless

7. Check Compliance with Local Standards

Part of how to check earthing system also involves verifying if your grounding system complies with local codes:

• Indonesia: SNI 0225 or PUIL 2011 (resistance typically <5 ohm)

• International: IEEE Std 80, IEC 60364, NEC, BS 7430

Get an audit or professional verification to ensure your system meets legal and insurance requirements.

How Often Should You Check the Earthing System?

Another important aspect of how to check earthing system is knowing when to check it. Here’s a recommended schedule:

• Annually: For general commercial or residential systems

• Every 6 months: For lightning protection systems or hospitals

• Monthly: For critical industries like data centers or refineries

• After every lightning storm or earthwork near grounding area

When Should You Upgrade Your Earthing System?

While learning how to check earthing system, keep an eye on these red flags indicating it’s time to improve:

• Earth resistance is consistently above acceptable limits

• Frequent equipment failures or electric shocks

• Old or corroded earth rods/conductors

• Expansion of electrical load or facility area

• New lightning protection system installed

Tools Required to Check Earthing System

To effectively follow steps in how to check earthing system, the following tools are commonly used:

Understanding how to check earthing system is essential for maintaining electrical safety, equipment protection, and ensuring compliance with standards. From visual inspection and resistance measurement to advanced step-voltage testing, each method plays a critical role in assessing grounding quality. Whether you’re a facility manager, electrician, or homeowner, incorporating regular earthing system checks into your maintenance routine can save lives and prevent costly failures.

For optimal results, use proper tools, follow national guidelines, and don’t hesitate to consult professional engineers if measurements fall outside safe ranges. So, the next time you wonder how to check earthing system, refer back to this guide—and stay grounded, safely!

Do you want to know information about how to check earthing system is proper or not, or another information about lightning protection systems?
Visit www.plasmacurrent.id or contact us at 0819-9754-2715
